N1K2-J Shiden-Kai
N1K2-J Shiden-Kai
Note: Base stats only (no upgrade installed)
Rank IV
Battle Rating 5.7
Type Fighter
Maximum Speed on height 613 km/h
Maximum Altitude 9,400 m
Turn Time 22 seconds
Rate of Climb 10.9 m/s
Takeoff Run 300 m
Armament 4x 20mm Type 99 Mk. 2 cannons (900 rds)
Burst Mass 4.15kg/s

The Kawanishi Shiden-Kai Model 21, Kawanishi N1K2-J (code name «George») is a single-seat monoplane fighter/interceptor currently sitting at Tier IV in the Japanese line. The upfront cost of a N1K2-J is 200,000 Lion.

Design, Development & Operational HistoryEdit

A single-seat, all-metal monoplane fighter with a closed canopy. The «Shiden» holds a unique place in the history of airplane construction. This land-based interceptor was based on the N1K1, which had been designed to support amphibious operations.

The first prototype N1K1 «Kyofu» («Mighty Wind») was flown on May 6, 1942, and mass production began in May of 1943. However, when the first seaplanes started to arrive on the front, the situation in the Pacific theater had changed so that this type of plane was simply no longer needed. Therefore, a land version project of the fighter was developed as a private initiative, based on the Kyofu. Originally it was planned that the only distinction between the two planes was that the Shiden-Kai would have retractable landing gear instead of floats, but it was quickly decided that the engine should be replaced with a more powerful alternative. A four-bladed propeller with a diameter of 3.3 meters was selected for the plane. Such a large propeller size, along with the mid-wing aerodynamic design, forced the plane to be fitted with elongated, telescoping landing gear struts which folded during retraction.

The land-based version made its first flight on December 12, 1942. The prototype's private designation was the X1, and in mass production its designation became N1K1-J «Shiden» («Purple Lightning»). Production began in August of 1943.

The new fighter proved to be an excellent interceptor. However, its operation was complicated by the frequent failure of its engine, the Homare 21, the complex design of its chassis, and its ineffective brakes. Consequently, the number of the N1K1-J's non-combat losses was very high. The next model of the Shiden was designed to eliminate these shortcomings.

The aircraft's redesign began simultaneously with the N1K1-J's military trials. The N1K2-J's first flight was made on December 31, 1943. The production model was designated the Shiden-Kai («Purple Lightning Improved») Model 21 Marine Fighter-Interceptor.

The new model, like its predecessor, featured a 14-cylinder air-cooled radial engine, the Nakajima Homare 21 NK9H, with a takeoff power of 1820 hp. It also retained the basic wing construction and armament of the N1K1-J. However, the Shiden-Kai was really a new plane. During the planning phase, special attention was given to ensuring ease of production and, at least to some extent, the use of readily available materials. The Shiden-Kai, unlike its predecessor, had a low-wing design which allowed the use of conventional landing gear. The new design was finally rid of the N1K1-J's main operational problems.

The shape of the fuselage was completely changed and somewhat lengthened, and the vertical tail fin was completely redesigned. The empty weight of the aircraft was decreased by 240 kilograms.

The N1K2-J was armed with 4 Type 99 Model 2 20mm wing-mounted cannons. The inner pair held 200 rounds of ammunition each and the outer held 250 each (900 rounds total).

On the two pylons suspended underneath its wings, the aircraft could carry two 250-kg type 98 or two 60-kg type 97 bombs. Or, it could carry unguided 60-kg No.27 rockets. In addition, an extra 400-liter fuel tank could be installed under the fuselage.

Because its center of gravity was towards the plane's rear, the N1K2-J was somewhat difficult to control, and was usually flown by experienced pilots (especially former Zero pilots) after they underwent retraining.
